Precision Diamond Roller for Particleboard & MDF Spreader Machine
PRODUCT PARAMETERS
Description
High-Wear 40Cr Steel Diamond Roller for Particleboard & MDF Spreader Machines | Custom CNC MachinedPrecision Diamond Roller for Particleboard & MDF Spreader Machine
Products Introduction:
The Diamond Roller is a critical component in particleboard and MDF forming/spreading machines, directly affecting mat uniformity, density distribution, and final board surface quality.
Manufactured from quenched & tempered 40Cr steel and processed by high-precision CNC machining, our rollers deliver stable paving performance, minimal wear, and long service life, even under continuous high-load production.
Technical Specifications
|
Parameter |
Details |
|
Material |
40Cr steel (Quenched & Tempered) |
|
Working Width |
4 ft / 6 ft / 8 ft (customizable) |
|
Roller Diameter |
Ø70 – Ø120 mm |
|
Surface Pattern |
Diamond / Mesh / Left & Right Helical (custom) |
|
Application Layer |
Face layer (fine teeth) / Core layer (medium–coarse) |
|
Precision |
Runout ≤0.05 mm/m |
|
Surface Roughness |
Ra 1.6 – 3.2 μm |
|
Service Life |
3–5 years (normal operation) |
Core Advantages:
High-Wear 40Cr Steel
Excellent toughness and abrasion resistance, no burrs after machining, suitable for long-term industrial operation.
CNC Precision Patterning
CNC spiral milling and grinding ensure consistent tooth depth, improving material distribution uniformity.
Full Customization Capability
Pattern geometry, roller size, tooth density, and application layer matched to your forming machine.
Strict Quality Control
Raw material inspection, heat treatment control, runout testing, and dynamic balance before shipment.
Applications
Particleboard forming & spreading lines
MDF / HDF forming machines
Wood-based panel mat forming systems
When Should a Diamond Roller Be Replaced?
Surface pattern wear or damage
Diameter deviation affecting mat uniformity
Abnormal vibration or noise
Board density instability
Service life approaching 3–5 years
Send us your machine brand, model, and roller drawing for a fast quotation.
We support OEM customization, global shipping, and a after sale services.
